AeroFLOW gentle feed transport
AeroFLOW optimizes gentle, air-driven feed transport for reliable, consistent delivery while protecting pellets from damage. Airflow is matched to the feed, route and equipment configuration.
Product details
Everything you need to evaluate AeroSpreader S1000
Engineered details
Features
AeroSpreader S1000 is a configurable pneumatic aquaculture feed broadcaster with a nominal 1,000 kg marine-aluminum hopper and Slide & Stow lid. Select the available metering, blower, broadcast equipment, controls and mounting arrangement for the feeding operation. Manual metering, volumetric metering and load-cell weighing are distinct arrangements; weighing and automation are included only when explicitly specified. Feed rate and coverage depend on the selected equipment and pellet properties.
Hopper and construction
Nominal 1,000 kg capacity; marine-aluminum hopper with Slide & Stow lid.
Pneumatic feed distribution
The blower supplies airflow to convey dry aquaculture feed pellets to the configured broadcast outlet.
Technical overview
Specifications
AeroSpreader S1000 is a configurable pneumatic aquaculture feed broadcaster with a nominal 1,000 kg marine-aluminum hopper and Slide & Stow lid. Select the available metering, blower, broadcast equipment, controls and mounting arrangement for the feeding operation. Manual metering, volumetric metering and load-cell weighing are distinct arrangements; weighing and automation are included only when explicitly specified. Feed rate and coverage depend on the selected equipment and pellet properties.
Nominal hopper capacity
1,000 kg. Usable feed mass depends on pellet bulk density and the loading arrangement.
Configuration and performance
Blower, metering, outlet and controls follow the selected equipment. Feed rate and coverage depend on pellet properties and operating conditions.
Why it matters
Benefits
AeroSpreader S1000 is a configurable pneumatic aquaculture feed broadcaster with a nominal 1,000 kg marine-aluminum hopper and Slide & Stow lid. Select the available metering, blower, broadcast equipment, controls and mounting arrangement for the feeding operation. Manual metering, volumetric metering and load-cell weighing are distinct arrangements; weighing and automation are included only when explicitly specified. Feed rate and coverage depend on the selected equipment and pellet properties.
Operator-directed feeding
Match feed placement and delivery to the feeding area and observed feeding activity.
Application-matched installation
Plan the mounting arrangement, loading access and operator position around the configured machine and intended site.
Specifications
| Hopper Chamber | 1-Chamber, 2-Chamber(1/2 1/2) |
| Fuel | Gas, Diesel, Electric |
| Engine | AB135 TEFC-Electric w/7.5hp Frequency Drive, AB150 TEFC-Electric w/10hp Frequency Drive, AB135 Pull Start 6.5HP, AB135 Electric Start 6.5HP, AB150 Pull Start 9HP, AB150 Electric Start 9HP |
| Metering | Manual, Volumetric |
| Broadcast | 4" Manual Periscope Feed Head, 4" Oscillating Periscope Feed Head, 4" Powered Periscope Feed Head, 4" 3m Boom with 3m Broadcast Tube, 4" 3m Boom with 6m Broadcast Tube, 5" Manual Periscope Feed Head, 5" Oscillating Periscope Feed Head, 5" Powered Periscope Feed Head |
| Outlet Size | 3", 4", 5" |
| Extension Tube | No Extension Tube, 4" Extension Tube, 5" Extension Tube |
| Gull Wing | No Gull Wing, Gull Wing 4", Gull Wing 5" |
| Periscope | None, Manual, Automatic |
| Control Type | Cable Controls 1000&above, Extended Cable Controls 1000&above 16ft/4.9m |
| Enclosure Panels | No Enclosure Panels, Enclosure Panels 1000 |
| Rotate Motor | No Rotate Motor, Rotate Motor 1000&above 1C, Rotate Motor 125&above 2C |
| Mobility | Stationary, Mobile Trailer |
| Bulk Bag Safety Ring | No Bulk Bag Safety Ring, Bulk Bag Safety Ring 1000 |
| Bulk Bag Cutter with Guide Frame | No Bulk Bag Cutter, Bulk Bag Cutter 1000 |
| Eductor | 4inch eductor, 5inch eductor, No Eductor |
| Rate Control | M100, No M100 |
| Inlet Silencer | No Inlet Silencer, AB135 Inlet Silencer (6.5 hp), AB150 Inlet Silencer (9 hp) |
| Hopper Capacity | 1000 kg |
